Neo Rare Earth Magnet
8mm X 6.0mm
Product Code: HW0097
Material: Neodymium magnets
Certification:RoHS passed
Grade: N35
Magnetization: Axially magnetized / Poles on Flat Ends
Triple Layer plated: NiCuNi
Shape: Sheet
Tolerance: +-0.1mm
Dimension: Diameter 8.0mm x thickness 6.0mm
Description
Neodymium (chemical symbol Nd) is element 60 on the periodic table.
It is a rare earth metal and forms one of the Lanthanides series.
When added to Iron (Fe) and Boron (B) (chemical formula Nd14Fe21B) the resultant magnets are the strongest magnets currently available.
Neodymium magnets are sometimes known as Neo,Neod or NIB magnets.
Neodymium magnets are usually coated Nickel-Copper-Nickel plating to prevent the iron from rusting.
Neodymium block magnet was made of NdFeB, have strong magnetic performances and appearance does not rust, usually placed in room temperature, the maximum operating temperature is 80 ° C ,and it never will demagnetize.
Applications
Acoustic field: the speaker, receiver, microphone, alarm, stage audio, car audio and so on.
Electronics: permanent magnetic actuator vacuum circuit breakers, magnetic relays, meter,sound meter, a reed switch, sensors.
Electrical field: VCM, CD / DVD-ROM, generators, motors, servo motors, micro-motors,vibration motors.
Machinery and equipment: magnetic separation, magnetic crane, magnetic machinery.
Healthcare: MRI scanners, medical equipment, magnetic health products and so on.
Other industries: magnetized Wax, pipe descaling, magnetic fixture, automatic mahjong machine,magnetic locks, doors for windows magnetic, magnetic luggage, leather magnetic toys,magnetic tools, gifts and packaging.
