LCD Black Characters with Blue backlight LCD1602

16 x 2

Product Code: LA0325

$6.50

Pay it in 4 payments of $1.62 with Afterpay

Buy 1+ $6.50 (incl. GST)

High quality LCD display module with blue backlight and white characters. Capable of displaying two rows of 16 characters on each row.
These displays feature high contrast and wide viewing angle. Each display has built in industry standard HD44780 equivalent LCD Controller. They can be driven by Raspberry Pi, Arduino, BeagleBone and many more
development boards.

Type: LCD

BACKLIGHT: Blue

CHARACTER COUNT:2 lines x 16 characters

OPERATING VOLTAGE:5V DC

MODULE DIMENSIONS:80mm (L) x 36mm (W) x 12mm (H)

VIEWING AREA SIZE:64.5mm (L) x 14.5mm (H)

CONTROLLER IC:SPLC780D or similar (HD44780 compatible)
