LCB244 LED Bar 24x 4W RGBW
Product Code: 150.575
The LCB244 is a LED bar with 4-in-1 RGBW LEDs. The unit is divided in 8 separately controllable sections. While using the fixture in stand-alone mode there are 54 pre-programmed shows that you can run automatically or sound activated, pick from the pre-set colour macros or create your own mixture of colours in RGBW mode. The extra P-Con output enables you to simply link the power of multiple units together into a single socket. Convection cooling for noiseless operation!
- 24x 4W 4-in-1 LEDs
- RGBW Colour mixing
- Colour presets
- Pre programmed shows
- Electronic Dimming: 0 - 100%
- DMX and Stand-alone mode
- Master/slave function
- Sound activated with adjustable sensitivity
- Auto mode with adjustable speed
- DMX in/output via 3-pin XLR
- Control panel with LED display
- Aluminium housing
- Powerconnector input/output
- Incl. Quick Lock Brackets
| Product colour | Black |
|---|---|
| Light source | 4-in-1 LED |
| Colours | Red, Green, Blue, White |
| LED power (single LED) | 4W |
| Quantity of LEDs | 24 |
| Beam angle | 11° |
| Field angle | 24° |
| Illuminance | 13.157 lx @ 1m |
| Flash rate per second | 1 - 23Hz |
| Modes | Automatic programs, DMX, Manual, Master/Slave |
| Sound to light mode | Yes |
| RDM | Yes |
| DMX channels | 4, 6, 9, 32, 36 |
| DMX connection | 3-pin XLR |
| Daisy chain | Yes (max. 6 bars) |
| IP rating | IP20 |
| Cooling | Convection |
| Display | LED |
| Power plug | P-Con |
| Power consumption | 1.983 - 0.912A |
| Power supply | 240VAC 50Hz |
| Dimensions (L x W x H) | 1000 x 55 x 105mm |
| Weight (kg) | 2,10 |
| Included accessories | Mounting bracket, Power cable |
