An entry-level 3-channel mixer with USB ports offering exceptional quality and value for money. Each music channel features a 3-band EQ for creative mixing, gain control to tweak the levels, with 3 phono inputs and 3 line inputs it is an ideal mixer for the vinyl or CD turntablist who wants a quality product at a great price.

  • 3 channel, 9 input mixer - 3 phono, 3 line, 2 USB, 1 mic
  • Individual gain controls per channel
  • 3-band EQ with up to 35dB cut per channel
  • Dedicated microphone channel with 2-band EQ
  • High level master output
  • Headphone mix control
  • Dual 10 LED monitor display
  • Supplied with a mains adaptor
  • USB ports to record and play via a computer
Power supply 9Vac, 1000mA
Frequency response 20Hz - 20kHz
Input impedance : Line 10-50k ohms
Input impedance : Mic 2.2k ohms
Input impedance : Phono 47k ohms
Input sensitivity : Line -12dBV (250mV) ±2dB
Input sensitivity : Mic -60dBV (1mV) ±2dB
Input sensitivity : Phono -50dBV (3.16mV) ±2dB
Output impedance : Headphone 33 ohms
Output impedance : Master 1k ohms
Output sensitivity : Headphone 1.1dBV (880mV) ±2dB
THD +N >0.02% (master = 0dBV output)
Dimensions 254 x 308 x 82.5mm (7U)
Weight 3.4kg

Pdficon Info / Manual
