Relay 24 volts DC

24 VDC

Product Code: RLY0195

$3.00

Pay it in 4 payments of $0.75 with Afterpay

Buy 1+ $3.00 (incl. GST)
Buy 10+ $2.85 (incl. GST)
Store Stock:
Henderson In Stock
Albany In Stock
Jump to:
Manuals and Downloads
Testing Voltage
Lifetime

Specifications

Contact : SPST-NO
Contact Material : AgNi
Rated Current : 5A
Max. Switching Current : 5A
Max. Switching Voltage : 250V AC / 150V DC
Max. Switching Power : 1250VA / 150W
Creepage/Clearance : 8/8mm
Operate/Release Time : 8/4ms
Coil/Contact : 5000V AC
Opening Contact : 750V AC
Mechanical : 5x106 Operations
Electrical : 1x105 Operations
Operating Temperature : -40...+70°C
Weight Approx. : 4,3g 17.5x10.0x12,5mm
